ProductOverview
InternalView
InternalViewofDevice
Item
Description
1
Printer
2
Batterycompartment
3
PrintedWiringAssembly(PWA)
4
KISSconnectorport
5
ECGpatientcableconnectorport
6
SDCardport
7
RJ45LANconnectionport
8
USBports(2)
9COMMAport
10COMMBport
11
RJ11PhoneporttoInternalModem
12
PowerSupply
