GE MAC 2000 Service Manual

ServiceSetup
12.PressEscorEnterwhenthetestisdone.
Thefollowingwindowopens.
13.Selectpassorfail:
•Ifthetestpassed,pressYes.
•Ifthetestfailed,pressNo.
a.Checktheconnection(cable)betweenthedisplayandPWAtoensureit
isconnectedproperlyandintact.
b.Runthedisplaytestagain.
c.Ifthedisplaytestfailsagain,replacethedisplayassemblyasdescribed
in“DisplayAssembly”onpage108.
TestingtheSpeaker
UsetheSpeakerTesttodetermineifthespeakerisworkingproperly.
1.OpentheDiagnosticTestswindowasdescribedin“SystemDiagnostics”on
page46.
2.SelectSpeakerTest.
3.Listenforabriefaudibletonecomingfromthespeaker.
Thefollowingwindowopens.
4.Selectpassorfail:
•Ifyouheardanaudibletone,pressYes.
•Ifyoudidnothearanaudibletone,pressNo.
Ifthespeakertestfailed,replacethemainPWAassemblyasdescribedin
“PWA”onpage120.
2053535-003C
MAC™2000ECGAnalysisSystem
49
