GE MAC 2000 Service Manual

Maintenance
5.Ifitwasinstalled,replacetheKISSpumpandtubing.
Seestep1throughstep4in“ReplacingtheKISSPumpAssembly”onpage127
forinstructions.
6.Replacethepowersupplyassembly.
Seestep1throughstep4in“ReplacingthePowerSupplyAssembly”onpage
92forinstructions.
7.Reattachthetopcoverassembly.
See“ReattachingtheTopCoverAssemblytotheDevice”onpage81for
instructions.
8.Reinsertthebattery.
Seestep6throughstep8in“ReplacingtheBattery”onpage74forinstructions.
9.ContinuewiththeappropriatefunctionalcheckoutprocedureforthisFRU.
See“FunctionalCheckout”onpage129formoreinformation.
RemovingtheChassis
Usethefollowingproceduretoremovethechassisfromthedeviceinordertoreplace
it.Forinstructionsonhowtopullthechassisinordertoaccesstheprinterorto
removethebottomcover,see“DetachingtheChassis”onpage82.
1.Removethetopcoverassembly,ifitishasnotbeenremovedalready.
See“RemovingtheTopCoverAssembly”onpage75formoreinformation.
2.Removethepowersupplyassembly.
Seestep3throughstep6in“RemovingthePowerSupplyAssembly”onpage
91forinstructions.
3.Ifitisinstalled,removetheKISSpumpandtubing.
Seestep2throughstep5in“RemovingtheKISSPumpAssembly”onpage126
forinstructions.
4.Removethefastenerssecuringthepowersupply/KISSpumpbasetothechassis,
asidentiedinthefollowingphotograph.
86
MAC™2000ECGAnalysisSystem
2053535-003C

GE MAC 2000 Specifications

General

ECG Type	Resting ECG
Number of Channels	12
Report Format	PDF, XML
Battery Type	Rechargeable lithium-ion
Connectivity	Ethernet
Data Storage	Internal memory
Display	High-resolution color LCD
Power Supply	Universal AC power supply
