5 LOGIC MODULES
This section contains a complete set of logic diagrams, which will help to explain the Autoreclose function. Most of
the logic diagrams shown are logic modules that comprise the overall Autoreclose system. Some of the diagrams
shown are not directly related to Autoreclose functionality, however, they may use some inputs are produce
outputs that are used by the Autoreclose system. These diagrams are shown in this section for the sake of
completeness.
5.1
CIRCUIT BREAKER STATUS MONITOR
The Circuit Breaker State Monitor logic is part of the Monitoring and Control functionality and is fully described in
that chapter. The logic diagram is repeated in this section because some of the outputs of this logic module are
used as inputs to some of the Autoreclose logic modules.
P543i/P545i Chapter 11 - Autoreclose
P54x1i-TM-EN-1 317
