GE MOTOR MANAGER 2 - Page 119

GE Power Management
MM2 Motor Manager 2 6-39
6 COMMUNICATIONS 6.5 MEMORY MAP
6
PROCESS
INTER-
LOCK
NAMES
continued
44596 4595 11F3 Process Intlk G Name chars 7 and 8 32-127 1 ASCII F10 ‘S ‘
44597 4596 11F4 Process Intlk G Name chars 9 & 10 32-127 1 ASCII F10 ‘IN’
44598 4597 11F5 Process Intlk G Name chars 11 & 12 32-127 1 ASCII F10 ‘TE’
44599 4598 11F6 Process Intlk G Name chars 13 & 14 32-127 1 ASCII F10 ‘RL’
44600 4599 11F7 Process Intlk G Name chars 15 & 16 32-127 1 ASCII F10 ‘OC’
44601 4600 11F8 Process Intlk G Name chars 17 & 18 32-127 1 ASCII F10 ‘K ‘
44602 4601 11F9 Process Intlk G Name chars 19 & 20 32-127 1 ASCII F10 ‘G ‘
44603 4602 11FA ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44608 4607 11FF ...Reserved... ... ... ... ... ...
44609 4608 1200 Process Intlk H Name chars 1 and 2 32-127 1 ASCII F10 ‘PR’
44610 4609 1201 Process Intlk H Name chars 3 and 4 32-127 1 ASCII F10 ‘OC’
44611 4610 1202 Process Intlk H Name chars 5 and 6 32-127 1 ASCII F10 ‘ES’
44612 4611 1203 Process Intlk H Name chars 7 and 8 32-127 1 ASCII F10 ‘S ‘
44613 4612 1204 Process Intlk H Name chars 9 & 10 32-127 1 ASCII F10 ‘IN’
44614 4613 1205 Process Intlk H Name chars 11 & 12 32-127 1 ASCII F10 ‘TE’
44615 4614 1206 Process Intlk H Name chars 13 & 14 32-127 1 ASCII F10 ‘RL’
44616 4615 1207 Process Intlk H Name chars 15 & 16 32-127 1 ASCII F10 ‘OC’
44617 4616 1208 Process Intlk H Name chars 17 & 18 32-127 1 ASCII F10 ‘K ‘
44618 4617 1209 Process Intlk H Name chars 19 & 20 32-127 1 ASCII F10 ‘H ‘
44619 4618 120A ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44624 4623 120F ...Reserved... ... ... ... ... ...
44625 4624 1210 Process Intlk I Name chars 1 and 2 32-127 1 ASCII F10 ‘PR’
44626 4625 1211 Process Intlk I Name chars 3 and 4 32-127 1 ASCII F10 ‘OC’
44627 4626 1212 Process Intlk I Name chars 5 and 6 32-127 1 ASCII F10 ‘ES’
44628 4627 1213 Process Intlk I Name chars 7 and 8 32-127 1 ASCII F10 ‘S ‘
44629 4628 1214 Process Intlk I Name chars 9 and 10 32-127 1 ASCII F10 ‘IN’
44630 4629 1215 Process Intlk I Name chars 11 & 12 32-127 1 ASCII F10 ‘TE’
44631 4630 1216 Process Intlk I Name chars 13 & 14 32-127 1 ASCII F10 ‘RL’
44632 4631 1217 Process Intlk I Name chars 15 & 16 32-127 1 ASCII F10 ‘OC’
44633 4632 1218 Process Intlk I Name chars 17 & 18 32-127 1 ASCII F10 ‘K ‘
44634 4633 1219 Process Intlk I Name chars 19 & 20 32-127 1 ASCII F10 ‘I ‘
44635 4634 121A ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
Table 6–12: MODBUS MEMORY MAP (Sheet 20 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
