6.5 MEMORY MAP 6 COMMUNICATIONS
6
PROCESS
INTER-
LOCK
NAMES
continued
44640 4639 121F ...Reserved... ... ... ... ... ...
44641 4640 1220 Process Intlk J Name chars 1 and 2 32-127 1 ASCII F10 ‘PR’
44642 4641 1221 Process Intlk J Name chars 3 and 4 32-127 1 ASCII F10 ‘OC’
44643 4642 1222 Process Intlk J Name chars 5 and 6 32-127 1 ASCII F10 ‘ES’
44644 4643 1223 Process Intlk J Name chars 7 and 8 32-127 1 ASCII F10 ‘S ‘
44645 4644 1224 Process Intlk J Name chars 9 & 10 32-127 1 ASCII F10 ‘IN’
44646 4645 1225 Process Intlk J Name chars 11 & 12 32-127 1 ASCII F10 ‘TE’
44647 4646 1226 Process Intlk J Name chars 13 & 14 32-127 1 ASCII F10 ‘RL’
44648 4647 1227 Process Intlk J Name chars 15 & 16 32-127 1 ASCII F10 ‘OC’
44649 4648 1228 Process Intlk J Name chars 17 & 18 32-127 1 ASCII F10 ‘K ‘
44650 4649 1229 Process Intlk J Name chars 19 & 20 32-127 1 ASCII F10 ‘J ‘
44651 4650 122A ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44656 4655 122F ...Reserved... ... ... ... ... ...
PRESET
CNTRS &
TIMERS
44657 4656 1230 Preset Running Hours 0-65535 1 --- F1 0
44758 4757 1231 Preset Stopped Hours 0-65535 1 --- F1 0
44759 4758 1232 Preset Number of Starts - High Order 0-65535 1 --- F1 0
44760 4759 1233 Preset Number of Starts - Low Order 0-65535 1 --- F1 0
44761 4760 1234 Preset Overload Trips 0-65535 1 --- F1 0
44762 4761 1235 Preset Thermistor Trips 0-65535 1 --- F1 0
44763 4762 1236 Preset Ground Fault Trips 0-65535 1 --- F1 0
44764 4763 1237 Preset Single Phase Trips 0-65535 1 --- F1 0
44765 4764 1238 Preset Acceleration Trips 0-65535 1 --- F1 0
44766 4765 1239 Preset Undercurrent Trips 0-65535 1 --- F1 0
44767 4766 123A Preset Under Power Trips 0-65535 1 --- F1 0
44768 4767 123B Preset Stalled Rotor Trips 0-65535 1 --- F1 0
44769 4768 123C Preset Control Command Trips 0-65535 1 --- F1 0
44770 4769 123D Preset Interlock Counter 0-65535 1 --- F1 0
... ... ... ...Reserved... ... ... ... ... ...
USER DEF.
MEM. MAP
DATA
44737 4736 1280 Address - User Definable Data 0100 0-12FF 1 --- F1 0
44749 4748 1281 Address - User Definable Data 0101 0-12FF 1 --- F1 0
44750 4749 1282 Address - User Definable Data 0102 0-12FF 1 --- F1 0
44751 4750 1283 Address - User Definable Data 0103 0-12FF 1 --- F1 0
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
44856 4855 12F7 Address - User Definable Data 0177 0-12FF 1 --- F1 0
Table 6–12: MODBUS MEMORY MAP (Sheet 21 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
