GE MOTOR MANAGER 2 User Manual

6-42 MM2 Motor Manager 2
GE Power Management
6.6 DATA FORMATS 6 COMMUNICATIONS
6
F9
con’t
28 = Process Interlock F ---
29 = Process Interlock G ---
30 = Process Interlock H ---
31 = Process Interlock I ---
32 = Process Interlock J ---
F10 Two ASCII Characters FFFF
32 to 127 = ASCII Character 7F00
32 to 127 = ASCII Character 007F
F11 Unsigned Integer: Starter Type FFFF
0 = Off ---
1=Full Voltage (Direct On Line)
Non-Reversing
---
2 = Full Voltage (Direct On Line)
Reversing
---
3 = Wye-Delta Open Transition ---
4 = Two Speed ---
5 = Inverter ---
6 = Slip Ring ---
7 = Autotransformer Open Transition ---
8 = Part Winding ---
9 = Wye Delta Closed Transition ---
10 = Autotransformer Closed
Transition
---
11 = Duty/Standby ---
12 = Soft Starter ---
F12 Unsigned Integer: AUX Relay
Operation
FFFF
0 = Non-Failsafe
1 = Failsafe
F13 Unsigned Integer - Ground CT Type FFFF
0 = 50:0.025 CBCT ---
1 = 5A Secondary CBCT ---
2 = Residual ---
F14 Unsigned Integer: Enable/Disable FFFF
0 = Disable ---
1 = Enable ---
F15 Unsigned Integer: VT Connection Type FFFF
0 = Line (A-B) ---
1 = Phase (A-N) ---
F16 Unsigned Integer: Manual/Auto FFFF
0 = Manual ---
1 = Auto ---
Table 6–13: DATA FORMATS (Sheet 3 of 15)
CODE DESCRIPTION BITMASK
F17 Interlock Input function FFFF
0 = Not Used ---
1 = Process Interlock A ---
2 = Process Interlock B ---
3 = Process Interlock C ---
4 = Process Interlock D ---
5 = Plant Interlock ---
6 = Lockout Reset ---
7 = Setpoint Access ---
8 = Auto Permissive ---
9 = Auto Start A ---
10 = Auto Start B ---
11 = Reset Emergency Stop Trip ---
12 = Reset Undercurrent Trip ---
13 = Two Wire Control ---
14 = Test Switch ---
15 = Remote Permissive ---
16 = Communication Select ---
17 = Interlock Counter ---
18 = AUX Relay 1 Inhibit ---
19 = Wye Delta 1M Contact ---
20 = Wye Delta 2S Contact ---
21 = U/V Restart Inhibit ---
22 = Autotransformer 2S Contact ---
23 = Process Interlock E ---
24 = Process Interlock F ---
25 = Process Interlock G ---
26 = Process Interlock H ---
27 = Process Interlock I ---
28 = Process Interlock J ---
29 = Stop A ---
30 = Stop B ---
31 = Remote Reset ---
32 = Motor Selector A/B ---
33 = Duty Select Man/Auto ---
34 = Bypass Contact ---
F18 Unsigned Integer:
Interlock Stop / Latched Trip
FFFF
0 = Interlock Stop ---
1 = Latched Trip ---
Table 6–13: DATA FORMATS (Sheet 4 of 15)
CODE DESCRIPTION BITMASK
