MM2 Motor Manager 2 6-47
6 COMMUNICATIONS 6.6 DATA FORMATS
6
F107 Trip Flags 1 FFFF
Ground Fault 0001
Overload 0002
Single Phase 0004
Acceleration Time 0008
Thermistor 0010
Stalled Rotor 0020
Undercurrent 0040
Underpower 0080
Analog Input High 0100
Analog Input Low 0200
Local Isolator 0400
Plant Interlock 0800
Serial Communication Failure 1000
Internal Fault 2000
Emergency Stop 4000
ESD Stop (Mod) 8000
F108 Trip Flags 2 FFFF
Process Interlock A 0001
Process Interlock B 0002
Process Interlock C 0004
Process Interlock D 0008
Parameters Not Set 0010
Faceplate Stop 0020
Process Stop 0040
Process Interlock E 0080
Process Interlock F 0100
Process Interlock G 0200
Process Interlock H 0400
Process Interlock I 0800
Process Interlock J 1000
Open Control Circuit 2000
Undervoltage 4000
Overvoltage 8000
Table 6–13: DATA FORMATS (Sheet 13 of 15)
CODE DESCRIPTION BITMASK
F109 Start Flags FFFF
Wye Delta start complete 0001
Two Wire Stop requested 0002
Serial Permissive (Starts Blkd if set) 0004
Not Used 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F110 Speed Status: FFFF
Speed at last Trip (0 = low, 1 = high) 0001
Speed at last Inrush calculation
(0 = low, 1 = high)
0002
Not Used 0004
Not Used 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
Table 6–13: DATA FORMATS (Sheet 14 of 15)
