GE MOTOR MANAGER 2 User Manual

A-2 MM2 Motor Manager 2
GE Power Management
A.1 COMMISIONING SUMMARY APPENDIX A
A
Ground Fault Trip Level Off
Gnd Fault Trip Delay On Run 1.0 sec.
Gnd Fault Trip Delay On Start 1.0 sec.
MOTOR PROTECTION – OPTIONS
Minimize Reset Time Enable
Stopped Motor Cool Time 30 min.
Overload Trip Reset Manual
Reset Lockout using Reset Key Enable
Phase Unbalance Alarm Enable
Thermal Capacity Alarm Off
Open Control Circuit Trip Enable
Reset Alarms Using Reset Key Enable
LOAD PROTECTION
Underpower Alarm Level Off
Underpower Alarm Delay 10 sec.
Underpower Trip Level Off
Underpower Trip Delay 10 sec.
Acceleration Time Alarm Off
Acceleration Time Trip Off
Load Increase Alarm Off
Undercurrent Alarm Level Off
Undercurrent Alarm Delay 10 sec.
Undercurrent Trip Level Off
Undercurrent Trip Delay 10 sec.
Stalled Rotor Trip Level 4.50 x FLC
Stalled Rotor Trip Delay 3.0 sec.
UNDER/OVERVOLTAGE PROTECTION
Undervoltage Alarm Level Off
Undervoltage Alarm Delay 10 sec.
Undervoltage Trip Level Off
Undervoltage Trip Delay 10 sec.
Overvoltage Alarm Level Off
Overvoltage Alarm Delay 10 sec.
Table A–1: MM2 COMMISSIONING (Sheet 3 of 8)
DESCRIPTION DEFAULT VALUE
Overvoltage Trip Level Off
Overvoltage Trip Delay 10 sec.
S3: PROCESS
PROGRAMMABLE INPUTS
Interlock Input 1 Not Used
Startup Override Delay 1 0 sec.
Running Override Delay 1 0 sec.
Operation 1 Stop
Instantaneous Alarm 1 Disable
IL1 Switch Type N.O.
Interlock Input 2 Not Used
Startup Override Delay 2 0 sec.
Running Override Delay 2 0 sec.
Operation 2 Stop
Instantaneous Alarm 2 Disable
IL2 Switch Type N.O.
Interlock Input 3 Not Used
Startup Override Delay 3 0 sec.
Running Override Delay 3 0 sec.
Operation 3 Stop
Instantaneous Alarm 3 Disable
IL3 Switch Type N.O.
Interlock Input 4 Not Used
Startup Override Delay 4 0 sec.
Running Override Delay 4 0 sec.
Operation 4 Stop
Instantaneous Alarm 4 Disable
IL4 Switch Type N.O.
Interlock Input 5 Not Used
Startup Override Delay 5 0 sec.
Running Override Delay 5 0 sec.
Operation 5 Stop
Instantaneous Alarm 5 Disable
Table A–1: MM2 COMMISSIONING (Sheet 4 of 8)
DESCRIPTION DEFAULT VALUE
