GE MOTOR MANAGER 2 User Manual

GE Power Management
MM2 Motor Manager 2 A-3
APPENDIX A A.1 COMMISIONING SUMMARY
A
IL5 Switch Type N.O.
Interlock Input 6 Not Used
Startup Override Delay 6 0 sec.
Running Override Delay 6 0 sec.
Operation 6 Stop
Instantaneous Alarm 6 Disable
IL6 Switch Type N.O.
Interlock Input 7 Not Used
Startup Override Delay 7 0 sec.
Running Override Delay 7 0 sec.
Operation 7 Stop
Instantaneous Alarm 7 Disable
IL7 Switch Type N.O.
Interlock Input 8 Not Used
Startup Override Delay 8 0 sec.
Running Override Delay 8 0 sec.
Operation 8 Stop
Instantaneous Alarm 8 Disable
IL8 Switch Type N.O.
Interlock Input 9 Not Used
Startup Override Delay 9 0 sec.
Running Override Delay 9 0 sec.
Operation 9 Stop
Instantaneous Alarm 9 Disable
IL9 Switch Type N.O.
Interlock Input 10 Not Used
Startup Override Delay 10 0 sec.
Running Override Delay 10 0 sec.
Operation 10 Stop
Instantaneous Alarm 10 Disable
IL10 Switch Type N.O.
Local Isolator Disable
Auto Permissive Indication Manual
Table A–1: MM2 COMMISSIONING (Sheet 5 of 8)
DESCRIPTION DEFAULT VALUE
Auto Mode Serial
Serial Permissive Disable
Start Block Alarm Disable
Disable Cmd Mode Change Disable
INTERLOCK NAMES
Process Interlock A Name Interlock A
Process Interlock B Name Interlock B
Process Interlock C Name Interlock C
Process Interlock D Name Interlock D
Process Interlock E Name Interlock E
Process Interlock F Name Interlock F
Process Interlock G Name Interlock G
Process Interlock H Name Interlock H
Process Interlock I Name Interlock I
Process Interlock J Name Interlock J
Intlk Counter Name
Intlk Counter
Intlk Counter Units Units
STOP CONFIGURATION
Field Stop Unlatched
Faceplate Stop Unlatched
Process Stop Unlatched
ANALOG INPUT
Analog Input Name Analog Input
Analog Input Units Units
Minimum Scale: 4 mA 0
Maximum Scale: 20 mA 1000
Analog Alarm Low Level Off
Analog Alarm Low Delay 5 sec.
Analog Alarm High Level Off
Analog Alarm HIgh Delay 5 sec.
Analog Trip Low Level Off
Analog Trip Low Override 5 sec.
Analog Trip Low Delay 5 sec.
Table A–1: MM2 COMMISSIONING (Sheet 6 of 8)
DESCRIPTION DEFAULT VALUE
