GE MOTOR MANAGER 2 User Manual

A-4 MM2 Motor Manager 2
GE Power Management
A.1 COMMISIONING SUMMARY APPENDIX A
A
Analog Trip High Level Off
Analog Trip High Override 5 sec.
Analog Trip High Delay 5 sec.
S4: CONTROL
UNDERVOLTAGE AUTO RESTART
Undervoltage Restart Enable
Immed. Restart Pwr Loss Time 200 ms
Delay Restart Pwr Loss Time 2.0 sec.
Restart Time Delay 2.0 sec.
AUX 1 RELAY CONFIG
Aux. Relay 1 Function Serial Control
Aux. Relay 1 Delay 5 sec.
Aux. Relay 1 Pre Start Delay 5 sec.
Aux. Relay 1 Post Start Delay Off
Energize On Motor Start Delay 5 sec.
De-energize on Motor Stop Dly 5 sec.
Aux. 1 Operation Non-failsafe
Delay Contactor G/F Trip By 0 ms
AUX 2 RELAY CONFIG
Aux. Relay 2 Function Serial Control
Aux. Relay 2 Delay 5 sec.
Aux. Relay 2 Pre Start Delay 5 sec.
Aux. Relay 2 Post Start Delay Off
Energize On Motor Start Delay 5 sec.
De-energize on Motor Stop Dly 5 sec.
Aux. 2 Operation Non-failsafe
Delay Contactor G/F Trip By 0 ms
S5: MONITORING
PLANT CONDITION
Motor Greasing Interval Off
Contactor Inspection Off
Max Motor Stopped Time Off
Table A–1: MM2 COMMISSIONING (Sheet 7 of 8)
DESCRIPTION DEFAULT VALUE
PRESET COUNTERS AND TIMERS
Preset Running Hours 0
Preset Stopped Hours 0
Preset Number Of Starts 0
Preset Overload Trips 0
Preset Thermistor Trips 0
Preset Ground Fault Trips 0
Preset Single Phase Trips 0
Preset Acceleration Trips 0
Preset Undercurrent Trips 0
Preset Underpower Trips 0
Preset Stalled Rotor Trips 0
Preset Control Trips 0
Preset Interlock Counter 0
S6: FACTORY DATA
PRODUCT FIRMWARE IDENTIFICATION
Mod Number(s) 000
Motor Manager 3 Version ---
Boot Program Version ---
Display Program Version ---
Supervisor Program Version ---
MM2 Hardware Revision ---
PRODUCT MODEL IDENTIFICATION
Order Code ---
Serial Number ---
Table A–1: MM2 COMMISSIONING (Sheet 8 of 8)
DESCRIPTION DEFAULT VALUE
