4 Maintenance
K0443 Revision A 4 - 2 [EN] English
4.5 Calibration
The instrument should be returned to the manufacturer or calibration facility, (Ref: Return
Goods /Material Procedure, Section 6.12).
To find the date of the last calibration, press Measure set-up/Status/Calibration history.
4.6 Replacement Parts
Use only the replacement parts listed (Ref: Table 4.2, Replacement Parts List).
WARNINGS
TURN OFF THE SOURCE PRESSURE AND CAREFULLY VENT THE PRESSURE LINES BEFORE
DISCONNECTING THE PRESSURE LINES FOR MAINTENANCE. PROCEED WITH CARE.
ISOLATE THE INSTRUMENT POWER SUPPLIES BEFORE REPLACING PARTS, WITH POWER
APPLIED THE INSTRUMENT CONTAINS LETHAL VOLTAGES.
Table 4.2 - Replacement Parts List
† refer to data sheet
4.7 Fuse Replacement (
Ref: Figure 4.1
Fuse Replacement)
(Ref: Testing and Fault Finding, Section 5) when to replace the fuse.
Remove
1. Set the power switch to OFF (if not rack-mounted got to step 3).
2. For access to rack-mounted instruments, the following actions maybe required:
a) Partially or completely withdraw the instrument.
b) Isolate pneumatic supplies.
c) De-pressurise all pressure supply inlet and output lines.
3.
Isolate the power supply to the instrument and disconnect the IEC power supply connector (1).
4. Remove the fuse carrier (2) from the power supply input socket assembly.
5. Remove the fuse cartridge (3).
Part number Description
- Fuse T2AH250V (PACE5000)
- Fuse T5AH250V (PACE6000)
IO-FILTER-KIT Kit, filter
CMX-XXXX † Module, pressure control
