PACE Pressure Controller User Manual
[EN] English 6 - 13 K0443 Revision A
RS232
Located on the rear panel an external RS232 connection requires the following:
IEEE 488
Located on the rear panel an external IEEE 488 connection requires: the following:
Ethernet
Located on the rear panel an external Ethernet connection requires the following:
Connector 9-way ‘D’ female wired as per Table 2-1
Communications RS232 point-to-point only
(DPI 520 daisy chain is not supported)
Baud Rate power-up default 9600, no parity & handshake = xon/xoff
Baud rates selectable ** 2400, 4800, 9600, 19k2, 38k4, 57k6 & 115k2
Parity None, Odd & Even
Flow control None, Hardware & xon/xoff
Protocols † SCPI, DPI 500, DPI 510, DPI 515, DPI 520
New data up-date rate refer to data sheet
Built-in EMC Filtering and Transient voltage protection
** Selectable through the user interface † Not all protocols available on all models.
Connector 24-way ‘D’ female wired as IEEE 488 standard
Communications IEEE 488 GPIB
Default Address 16
Protocols † SCPI, DPI 500, DPI 510, DPI 515, DPI 520
New data up-date rate refer to data sheet
Built-in EMC filtering and transient voltage protection.
† Not all protocols available on all models.
Connector Ethernet RJ45
Protocol SCPI
Terminator CR/LF
Default Address Auto IP (0.0.0.0)
Host name PACExxxxxx (where xxxxxx = serial number)
Web Password 0268
Access control Open
Reset LAN Settings Selected in Supervisor set-up menu
