PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
6-5
6-3 TABLE OPERATION
6-3-1Emergency Stop
The Proteus XR/a Table is equipped with an emergency stop switches
located on the left and right side of the table. (See Illustration 6-1)
In the event of an emergency, press the emergency stop in with force.
When normal conditions are confirmed, turn the button clockwise so the
table can be powered up.
6-3-2 Raising and Lowering the Table Top
To raise and lower the table, press the foot pedal two consecutive times.
This will activate the foot pedal switches. (See Illustration 6-1.)
Raising the Table top
To raise the table, press the control pedal two consecutive times and
hold down until the desired height is reached.
Lowering the Table top
To lower the table, press the control pedal two consecutive times and
hold down until the desired height is reached.
Note: The Table top automatically stops when reaching its maximum and
minimum height: 800 mm (31-1/2”nono) and 500 mm (19-2/3”). It
may also stop when the operator takes their foot off of the pedal.
The Proteus XR/a Table is equipped with a collision detection system. If
contact is made between the table top and a foreign object such as a
stool while lowering the table top, the requested motion will automatically
stop until the collision condition is removed. This is accomplished by
either clearing the foreign object from the table top movement path or by
requesting the reverse movement of the table top.
To avoid jamming, do not put your foot right under the table outer
cover when table is driven down to the lower limit.
DO NOT TRY TO RAISE OR LOWER THE TABLE BY MEANS OF
THE CONTROL PEDAL WHILE THE TABLE AND XT SUSPENSION
ARE CONNECTED BY A TOMO-LINK UNLESS XT LOCKS ARE
RELEASED, OTHERWISE, THE TOMO-LINK MAY BE DAMAGED.
REFER TO DIRECTION 2122884-100.
6-3-3 Inhibition Button for Table Elevation or Table Top movement
To prevent the table elevation or Table top movement, presses down the
inhibition button. This button will simultaneously light symbolizing and the
table functions are locked.
When patients are getting on and off the table, to prevent possible
falling of the patients from the Table, press down the inhibition
button to prohibit the Table Elevation and Table top movement.
6-3-4 Positioning the Table top Longitudinally and Transversely
To position longitudinally and transversely with respect to the X-ray tube,
press either outer control pedal. Then you can move the Table top to the
desired position manually.
To lock the Table top, release the control pedal.
WARNING
CAUTION
CAUTION
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
