PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
2-2
2-3 Power ON and OFF
2-4 Electrical Type
2-5 Electrical Current
2-6 Ground
2-7 Proteus XR/a Collimator / Eclipse Proteus Collimator
2-8 Emergency Button
Power ON switch or switch position that applies mains voltage. Indicated
connection to the mains for all mains switches or their positions. This
symbol is used in all cases where safety is involved.
Power OFF switch or switch positions that removes mains voltage.
Indicated disconnection from the mains for all mains switches or thei
positions. This symbol is used in all cases where safety is involved.
Type B Equipment. Equipment providing a particular degree of protection
again electrical shock regarding leakage current and protective
grounding per IEC 601-1.
Alternating Current. Indicates equipment that is suitable for alternating
current only.
Direct Current. Indicates equipment that is suitable for direct current only.
Functional Earth (ground) Terminal. Terminal directly connected to a
point of a measuring supply or control circuit or to a screening part which
is intended to be earthen for functional purposes.
Protective Earth (ground). Identifies any terminal that is intended fo
connection of an external protective conductor to protect against
electrical shock in case of a fault.
Control for indicating radiation field by using light.
Immediately removes power from table.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
