PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
13-2
Altitude and Atmospheric Pressure
See Table 13-2.
TABLE 13-2
ALTITUDE AND ATMOSPHERIC PRESSURE
PRODUCT OR ALTITUDE ATMOSPHERIC PRESSURE
COMPONENT
IN-USE STORAGE IN-USE STORAGE
MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX.
Elevating table -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
XT OTS -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
Generator -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
PDU -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
System Console -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
Tomography
Option
-30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
X-ray Tube (Rad
14)
-30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3048 m
(10000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
X-ray Tube (MX
100)
-30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
6096 m
(20000 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
SG120 Wallstand -30.5 m
(-100 ft.)
2440 m
(8005 ft.)
-30.5 m
(-100 ft.)
3000 m
(9842 ft.)
650 hPa 1060 hPa 500 hPa 1060 hPa
13-2 Equipment Heat output (Dissipation)
See Table 13-3.
TABLE 13-3
HEAT OUTPUTS (BY COMPONENT)
PRODUCT OR MAXIMUM HEAT OUTPUT (BTU/hr) MAXIMUM HEAT OUTPUT (WATTS)
COMPONENT IN-USE IN-USE
Table Assembly 1500 500
Generator 2036 597
PDU 500 145
Console 180 60
X-ray Tube (Rad 14) 2288 671
X-ray Tube (MX 100) 3600KHU/hr 740
