PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-18
14- 10 Printer Specifications
TABLE 14-30
EPSON MODEL-180 PRINTER SPECIFICATIONS
Printing Method
Impact dot matrix printer (6 print solenoids)
Print Format
Number of Total Dots Max. 144 dots/1 dot line
Number of Column Max. 24 columns (in case of 5x7 dot matrix and 1 dot
column space)
Print Speed
1 Dot Line
Typ. 75ms (continuous printing, 4.8VDC, 25°C)
5x7 Dot Matrix (3 dots line space)
Typ. 1.7l/s (continuous printing, 4.8VDC, 25°C)
Character Size
Dot Pitch Horizontal 0.33mm Vertical 0.37mm
5x7 Dot Matrix 1.7(W)×2.6(H) mm
Copy Capacity 1(original)+1(copy) (in the case of conform to
specifications for pressure sensitive paper M-180 series)
Paper 57.5mm width wood free paper or specified pressure
sensitive paper
Paper Feed Paper is fed automatically per 1 dot line.
Fast paper feeding is possible. (Typ. 4.0l/s at 4.8VDC,
25°C, continuous printing)
With paper free mechanism and manual paper feed knob
Inking Ribbon cassette (ERC-09 or ERC-22 ). Ribbon is fed
automatically during motor revolution.
Motor
Terminal Voltage 4.8+0.7/-1.0 VDC
Mean Current
Typ. 0.2A (4.8VDC, 25°C, the value measured by the
ammeter)
Timing Detector Tachometer-Generator (directly connected with motor)
Reset Detector Reed switch
Print Solenoid
Terminal Voltage 4.8+0.7/-1.5 VDC.
DC Resistance
1.5 ohms +/-10% (at 25°C)
Fast Paper Feed Trigger Magnet
Terminal Voltage 4.8+0.7/-1.0 VDC (The difference between motor terminal
voltage and it should be 1V or less.)
DC Resistance
20 ohms +/-10% (at 25°C)
Connection
Printer Side P.C. board with 2.54mm pitch copper leaf pattern that is
fixed on printer frame.
Circuit Side Cable wires or lead wires
Operating Ambient Temperature
0°C to 50°C
Reliability MCBF 1 million lines (In case of printing with print mode
in attached table 1)
Dimensions 9.06(w)x4.11(d)x3.75(h) inch (except for a manual paper
feed knob)
Weight 250 g +/-10%
DOSE Display Deviation
≤25%
FOR TRAINING PURPOSES ONLY!
