PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-17
14-9-2 MX 100 Tube Specifications
The MX 100 X-Ray Tube is used in Three-Phase 65 or 80 kW systems.
See Table 14-29.
TABLE 14-29
MX 100 X-RAY TUBE SPECIFICATIONS
Parameter Specification
Rotating Anode 3000/3600 and 9000/10800rpm
kVp Capacity 150 kVp
Large Focus 1.25mm, 100kW, 1000mA
Small Focus 0.6 mm, 36kW, 400mA
Target Angle
12.5 °
Acces Time
Transition 0→LS
1.2s
Transition LS →0
3s/70Vdc Brake
Tube Protection
Cooling Type Air Blower
Anode Thermal Capacitance 260 kJ
Housing Thermal Capacitance 1110 kJ
Housing Cooling Rate 740W Max average power
The maximum x-ray tube loading power 150KV, 5184mAs per hour
Maximum tube housing temperature
71±15°
Insert Filtration 0.8 mm Aluminium equivalency at 150kVp
Small Focal spot Nominal value 0.6 (Specifications as per IEC)
Large Focal spot Nominal value 1.25 (Specifications as per IEC)
Continuous Mean Power 740 Watts (600X Ray Watts + accessories)
Radiographic ratings 96kW for large filament and 32kW for Small filament
Noise 55dB @ 1 meter
Radiation containment 50 mR/h
Tube Life B10= 6.7 months, B50= 36.1 months and DOA: 3%
kV operating range 40-150kV
Target angle 12.5 Degrees
Weight 29.5kg +/- 2.25kg
HV Stability 0 Spits during Functional Test
Safety circuit Normally closed pressure switch.
Maximum voltage Anode or Cathode to ground 82kVp
Anode Heat storage capacity 260kJ
Tube unit heat storage capacity 1110kJ
Anode Heat dissipation rate 75 kHU per minute
Tube unit heat dissipation rate 60 kHU per minute, with Blower operating
Frame Glass
Rotation speed 50/60 Hz and 150/180Hz
Anode Diameter 100mm
Target material Tungsten/ Rhenium
Cooling Air Blower, 740W Max average power.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
