GE Proteus XR/a User Manual

PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
14-10
14- 4 System Console Specifications
See Table 14-19
TABLE 14-19
GENERAL SPECIFICATIONS
Dimensions System Console
Long: 350 mm (13-3/4 in.)
Width: 230 mm (9 in.)
Depth: 60 mm (2-1/2 in.)
Weight: 8 kg (17-1/2 lbs.) (with pedestal)
Touch Screen 10.4”
Floppy Drive 1.44MB
APR 1728 programmable
Power Supply
System Console 12VDC, 5Amps
14- 5 OTS Specifications
See Table 14-20.
TABLE 14-20
OTS SPECIFICATIONS
Parameter Specification
Longitudinal Focal Spot Travel 2640mm to 5020mm
Lateral Focal Spot Travel 1200mm@2m bridge
2100mm@3m bridge
Vertical Focal Spot Travel 1500 mm (59 in.)
Horizontal Tube Rotation +/- 180 degrees; detents at each 90 degree position
Vertical Tube Rotation + 25/-10 degrees
Focal Spot to Ceiling Distance (Horizontal) Min 733mm (28-7/8 in.) Max 2232mm (87-7/8 in.)
Focal Spot to Ceiling Distance (Vertical) Min 713mm (28-1/16 in.) Max 2211mm (87-1/16 in.)
Distance between Center Lines of Ceiling Mounting
Bolt Holes in Stationary rails
1.43m(56”), or 1.27m(50”), or 1.22m(48”)
Extension 190mm, 287mm
OTS RAD Suspension Weight 431kg (50lbs)
Stationary rail length 3470mm to 5790mm
OTS Console
kV Control and Display
40−150
mAs Control and Display
0.5−630
SID Display
0−200
Tube Angle Display
−180 to +180
Power Supply
OTS Console +5VDC, 2.5A
+12VDC, A
- 12VDC, A
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
