PROTEUS XR/a
GE MEDICAL SYSTEMS Operator Manual
REV 11 DIRECTION 2259724-100
10-1
CHAPTER 10 ACCESSORIES
10-1 Introduction
The following accessories are available with Proteus XR/a Systems:
• Abdomen Compression Band
• Patient Hand Grips
• Collimator Cone
FOR CONTINUED SAFE USE OF THIS EQUIPMENT, USE ONLY
MANUFACTURER RECOMMENDED ACCESSORIES
ACCESSORIES SHOULD BE PROPERLY ATTACHED TO THE TABLE AND
POSITIONED SO AS NOT TO INTERFERE WITH SYSTEM MOTIONS.
10- 2 Accessories
10-2-1 Abdomen Compression Band
Installation:
1. Depress the lock, then release clamp.
2. Position the clamp, then depress the handle.
3. Fasten the compression band.
WARNING
WARNING
Lock
Adapting screw
Safety screw
Lock
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
