GE T60 - Page 593

GE Multilin T60 Transformer Protection System B-21
APPENDIX B B.4 MEMORY MAPPING
B
257B PMU 1 Positive Sequence Voltage Angle -180 to 180 ° 0.1 F002 0
257C PMU 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
257E PMU 1 Negative Sequence Voltage Angle -180 to 180 ° 0.1 F002 0
257F PMU 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2581 PMU 1 Zero Sequence Voltage Angle -180 to 180 ° 0.1 F002 0
2582 PMU 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
2584 PMU 1 Phase A Current Angle -180 to 180 ° 0.1 F002 0
2585 PMU 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
2587 PMU 1 Phase B Current Angle -180 to 180 ° 0.1 F002 0
2588 PMU 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
258A PMU 1 Phase C Current Angle -180 to 180 ° 0.1 F002 0
258B PMU 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
258D PMU 1 Ground Current Angle -180 to 180 ° 0.1 F002 0
258E PMU 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2590 PMU 1 Positive Sequence Current Angle -180 to 180 ° 0.1 F002 0
2591 PMU 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2593 PMU 1 Negative Sequence Current Angle -180 to 180 ° 0.1 F002 0
2594 PMU 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2596 PMU 1 Zero Sequence Current Angle -180 to 180 ° 0.1 F002 0
2597 PMU 1 Frequency 2 to 90 Hz 0.001 F003 0
2599 PMU 1 df/dt -327.67 to 327.67 Hz/s 0.01 F002 0
259A PMU 1 Configuration Change Counter 0 to 655.35 0.01 F001 0
259B Reserved (4 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Integer Values (Read Only Actual Value Registers)
2699 PMU 1 SOC Timestamp 0 to 4294967295 seconds 1 F003 0
269B PMU 1 FRAMESEC Timestamp 0 to 4294967295 seconds 1 F003 0
269D PMU 1 STAT Flags 0 to 4294967295 --- 1 F003 0
Phasor Measurement Unit Aggregator Actual Values (Read Only)
26BD PMU 1 Aggregator PDU Size --- --- --- F001 0
IEC 61850 GGIO5 Configuration (Read/Write Setting Registers) (16 Modules)
26D0 IEC 61850 GGIO5 uinteger Input 1 Operand --- --- --- F612 0
26D1 IEC 61850 GGIO5 uinteger Input 2 Operand --- --- --- F612 0
26D2 IEC 61850 GGIO5 uinteger Input 3 Operand --- --- --- F612 0
26D3 IEC 61850 GGIO5 uinteger Input 4 Operand --- --- --- F612 0
26D4 IEC 61850 GGIO5 uinteger Input 5 Operand --- --- --- F612 0
26D5 IEC 61850 GGIO5 uinteger Input 6 Operand --- --- --- F612 0
26D6 IEC 61850 GGIO5 uinteger Input 7 Operand --- --- --- F612 0
26D7 IEC 61850 GGIO5 uinteger Input 8 Operand --- --- --- F612 0
26D8 IEC 61850 GGIO5 uinteger Input 9 Operand --- --- --- F612 0
26D9 IEC 61850 GGIO5 uinteger Input 10 Operand --- --- --- F612 0
26DA IEC 61850 GGIO5 uinteger Input 11 Operand --- --- --- F612 0
26DB IEC 61850 GGIO5 uinteger Input 12 Operand --- --- --- F612 0
26DC IEC 61850 GGIO5 uinteger Input 13 Operand --- --- --- F612 0
26DD IEC 61850 GGIO5 uinteger Input 14 Operand --- --- --- F612 0
26DE IEC 61850 GGIO5 uinteger Input 15 Operand --- --- --- F612 0
26DF IEC 61850 GGIO5 uinteger Input 16 Operand --- --- --- F612 0
IEC 61850 Received Integers (Read Only Actual Values) (16 Modules)
26F0 IEC 61850 Received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 Received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
