7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0 to 600 s 0.05 F001 0
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B90 ...Repeated for User Programmable Pushbutton 2
7BC0 ...Repeated for User Programmable Pushbutton 3
7BF0 ...Repeated for User Programmable Pushbutton 4
7C20 ...Repeated for User Programmable Pushbutton 5
7C50 ...Repeated for User Programmable Pushbutton 6
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7DE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
7DD0 ...Repeated for User Programmable Pushbutton 14
7E00 ...Repeated for User Programmable Pushbutton 15
7E30 ...Repeated for User Programmable Pushbutton 16
Distance (Read/Write Grouped Setting)
7E8C Distance Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7E8D Memory Duration 5 to 25 cycles 1 F001 10
7E8E Force Self-Polarization 0 to 4294967295 --- 1 F300 0
7E90 Force Memory Polarization 0 to 4294967295 --- 1 F300 0
Distance (Read Only)
7E94 AB Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7E96 AB Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7E98 AB Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7E9A AB Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7E9B BC Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7E9D BC Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7E9F BC Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EA1 BC Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EA2 CA Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
7EA4 CA Loop Reactance -2147483647 to
2147483647
ohm 1 F060 0
7EA6 CA Loop Impedance Magnitude 0 to 2147483647 ohm 1 F060 0
7EA8 CA Loop Impedance Angle -359.9 to 0 degrees 0.1 F002 0
7EA9 AG Loop Resistance -2147483647 to
2147483647
ohm 1 F060 0
Table B–10: MODBUS MEMORY MAP (Sheet 41 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
