B-82 T60 Transformer Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
EBE7 PMU Ib Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE8 PMU Ic Calibration Angle -5 to 5 ° 0.05 F002 0
EBE9 PMU Ic Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBEA PMU Ig Calibration Angle -5 to 5 ° 0.05 F002 0
EBEB PMU Ig Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBEC PMU Sequence Voltage Shift Angle -180 to 180 ° 30 F002 0
EBED PMU Sequence Current Shift Angle -180 to 180 ° 30 F002 0
Phasor Measurement Unit Network Reporting Configuration (Read/Write Setting)
EC48 PMU Network Reporting Function 0 to 1 --- 1 F102 0 (Disabled)
EC49 PMU Network Reporting ID Code 1 to 65534 --- 1 F001 1
EC4A PMU TCP port number 1 to 65535 --- 1 F001 4712
EC4B PMU UDP port number 1 1 to 65535 --- 1 F001 4713
EC4C PMU UDP port number 2 1 to 65535 --- 1 F001 4714
Settings File Template (Read/Write Setting)
ED00 FlexLogic Displays Active 0 to 1 --- 1 F102 1 (Enabled)
ED01 Template Access --- --- --- F205 (none)
Setting File Template (Read Only)
ED07 Last Settings Change Date 0 to 4294967295 --- 1 F050 0
Settings File Template (Read/Write Setting)
ED09 Template Bitmask (750 items) 0 to 65535 --- 1 F001 0
Phasor Measurement Unit Records (Read Only)
EFFF PMU Recording Number of Triggers 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 74 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
