GEA VARIVENT Vacuum Valve V - Pipe Ends; Tools

Technical Data
Tools
42
Operating Instructions · VARIVENT
®
Vacuum Valve V
Edition 2016-06-30
Pipe Ends
Tools
Dimensions for Pipes in DN
Metric
DN
Outside diameter Wall thickness Inside diam-
eter
Outside diameter
acc. to
DIN 11850
65 70 2.0 66 x
80 85 2.0 81 x
100 104 2.0 100 x
150 154 2,0 150 x
Dimensions for Pipes in Inch OD
Inch OD Outside diameter Wall thickness Inside diameter Outside diameter acc.
to
BS 4825 Part 1
2.5" 63.5 1.65 60.2 x
3" 76.2 1.65 72.9 x
4" 101.6 2.11 97.38 x
Dimensions for Pipes in Inch IPS
Inch IPS Outside diameter Wall thickness Inside diameter Outside diameter
acc. to
DIN EN ISO 1127
3" 88,9 2,3 84,3 x
4" 114,3 2,3 109,7 x
6" 168.3 2.77 162.76 x
Tool Part no.
Hose cutter 407-065
Open end spanner, a/f 13-15 408-035
Open end spanner, a/f 14-17 408-045
Open end spanner, a/f 22-24 408-040
