Geeetech A20T - 5.2 Wiring Connections

9
SHENZHEN GETECH TECHNOLOGY CO., LTD
in picture (5-3).
(Picture 5-3)
 Filament holder kit was assembled as shown in Picture (5-4) with 4 M3x16 screws, 4 M3
nuts and 4 M3 washers, a total of 3 sets were assembled.
(Picture 5-4)
5.2 Wire connection
 Insert the three Teflon tubes into the quick-insert connector of the three extruders
respectively. It can be inserted into the quick- insert connectors of E0, E1 and E2 as needed.
Details see picture (5-5).
