Geely CK Series 2007 User Manual

179

Inspect voltage between terminals
Standard:
Result and solution:
Abnormal Repair or replace the harness or connector
Normal Inspect the speed sensor output signal
3 Inspect the speed sensor output signal
Inspect voltage
 Hold the front wheels up
 Push the shift lever to NEUTRAL
 Turn the ignition switch to ON
 Slowly turn the front wheel, measure the voltage between terminal 1 and 2
Standard voltage is as follows:
Voltage changes alternately
Result and solution:
Normal Repair or replace the harness or connector
Abnormal replace the speed sensor
Turning Wheels
Below 0.5V
Tester connection Condition Standard condition
3 - ground Turn the ignition switch to ON 7.5 – 9V
