Gefen EXT-DVIK-MV-41 - Specifications

Connectors, Controls, and Indicators
Video Input • 4 x DVI-I, 29-pin, female (digital only)
Video Output • 2 x DVI-I, 29-pin, female (digital only)
USB (front panel) • 2 x Type A, 5V DC at 1A max shared current
USB (rear panel) • 2 x Type A, 5V DC at 1A max shared current
• 4 x Type B
Microphone • 1 x 3.5mm mini-mono (input)
• 4 x 3.5mm mini-mono (output)
L/R Audio • 4 x 3.5mm mini-stereo (input)
• 1 x 3.5mm mini-stereo (output
RS-232 • 1 x DB-9, female (input)
• 1 x DB-9, male (output)
Power switch • 1 x rocker-type
Grounding • 1 x machine screw (rear chassis)
Front Panel Buttons • 10 x tact-type, blue backlight
• 6 x tact-type
Power Supply Connector • 1 x 3-pin, locking
Power Indicator • 1 x LED, blue
Video B Indicator • 4 x LED, blue
Audio Indicator • 4 x LED, blue
USB Indicator • 4 x LED, blue
Operational
Maximum Pixel Clock • 165 Mhz
Maximum TMDS Clock • 165 MHz
Power Supply • 12V DC
Power Consumption • 40W maximum
Operating Temperature • +32 to +122 °F (0 to +50 °C)
Operating Humidity • 5% to 90% RH, non-condensing
Storage Temperature • -4 to +185 °F (-20 to +85 °C)
Relative Humidity • 0% to 95% RH, non-condensing
MTBF • 50000 hours
Physical
Dimensions (W x H x D) • 17.2” x 1.2” x 7.9” (437mm x 30mm x 200mm)
Unit Weight • 3.7 lbs (1.6 kg)
