Basic Operation
OSD Menu
Read Monitor EDID
The Read Monitor EDID function is designed to be used if the 4x1 DVI KVM Multiview
Switcher is unable to automatically read the EDID of the display connected to Video A.
If the display’s EDID is corrupted, then the switcher will automatically use the built-in EDID
on the switcher.
1. Enter the menu system. See Accessing the Menu System (page 39) for more
information.
2. Make sure the EDID Mode is set to External.
3. Select the Information option using the ▲ or ▼ keys on the computer keyboard.
4. Press the Enter key to display the Information screen.
F1
F2
F3
F4
Ins
Home
Main menu
Full view
PIP view
Quad view
PAP view
Edit
Video B
Esc
Enter
A
H
I
Exit
Select
Switch Audio
Switch USB
PIP display
Input
01
02
03
04
KVM ID: 01 / 02
AUD USB VID-A VID-B PIP
AUD USB VID-A VID-B
PIP
z
z
X
X
X
X
X
X
Select
Name VID USB
PC01
PC02
PC03
PC04
Settings
Information
Exit
F1
F2
F3
F4
Information
Full view
PIP view
Quad view
PAP view
Esc
Enter
W S
Exit
Select
Navigate
Read Monitor EDID
Upgrade Firmware
Monitor Model
Preferred Timing
Firmware Version
DVIK-MV-41
1920x1080
FW 1.0.2
Main Menu
Settings
Exit
Basic Operation
