Basic Operation
5. To zoom-in or zoom-out of the subordinate window, use the scroll wheel on the
mouse. Make sure that the mouse cursor is placed over the subordinate window
before zooming.
Note that the zoom-in and zoom-out direction (scroll up or scroll down) will depend
upon the scroll settings of the mouse.
6. Once the subordinate window is set to the desired position and size, click the scroll
button to dismiss the Mode menu.
Window Management in PAP Mode
In PAP mode, the 4x1 DVI KVM Multiview Switcher manages subordinate windows by
switching the main window with a subordinate window when a different source is selected.
The following example illustrates that moving a subordinate window to the main window is
not arbitrary.
1. Given that the main window is Source 1:
PIP & PAP Modes
2
1
3
4
To Next Page
