Sample Wiring Diagram
Getting Started
RS-232 CABLE
DVI Display
DVI Display
Keyboard
Mouse
EXT-DVIK-MV-41
DVI KVM
Multiview Switcher
EXT-DVIK-MV-41
USB CABLE
Mic
MIC CABLE
DVI CABLE
4x
Multimedia
PC/Servers
3.5mm MINI-STEREO CABLE
RS-232
Automation
Control Device
USB Printer
USB External HDD
Powered
Speakers
Daisy-Chain
to a second
EXT-DVIK-MV-41’s
RS-232 In
RS-232
In
RS-232
Out
Installation
page | 9
