page | 5
Introduction
ID Name Description
1 Grounding terminal Connect a grounding wire from this
terminal to an approved Earth ground.
2 Main Press this switch to power-on or power-
off the unit.
3 12V DC Connect the included power supply from
this power receptacle to an available
electrical outlet.
4 RS-232 In Connect an RS-232 cable from this
power to an RS-232 controller.
5 RS-232 Out Connect an RS-232 cable from this port
to the RS-232 device to be controlled.
6 Keyboard / Mouse Connect a keyboard and mouse to these
USB ports.
7 Video A / Video B Connect a DVI cable from each of these
ports to a DVI display. The Video A port
is the main display and supports multiple
windows. Video B is the auxiliary
display. See Display Nomenclature
(page 14) for more information.
8 Mic (Workstation) Connect a 3.5mm mini-stereo cable
from this jack to the Mic jack on the
workstation computer.
9 L/R Out Connect a 3.5mm mini-stereo cable from
this jack to a pair of powered speakers.
10 Mic
(Source 1 - Source 4)
Connect a 3.5mm mini-stereo cable from
this jack to the Mic jack on the source
computer.
11 L/R In
(Source 1 - Source 4)
Connect a 3.5mm mini-stereo cable
from this jack to the Line Out jack on the
computer.
(continued on next page)
