166 ADV200 • Functions description and parameters list
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.54 4656MotPhLossholdoff ms UINT16 800 800 10000 ERW FVS
Represents the time the alarm condition has to persist before the alarm is actually generated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.55 4658MotPhLossthreshold A FLOAT CALCF 0 CALCF ERW FVS
Represents a current threshold for generating the alarm.
The value has to be lower than the torque current value set in the drive.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.56 4700Alarmdigsel1 ENUM No alarm 0 60 ERW FVS
24.57 4702Alarmdigsel2 ENUM No alarm 0 60 ERW FVS
24.58 4704Alarmdigsel3 ENUM No alarm 0 60 ERW FVS
24.59 4706Alarmdigsel4 ENUM No alarm 0 60 ERW FVS
Setting of the alarm signal to enable on a digital output. The digital output is selected using parameters Alm
digoutmon1÷4, which can be enabled in the L_DIGSEL1 selection list.
0 No alarm
1 Overvoltage
2 Undervoltage
3 Ground fault
4 Overcurrent
5 Desaturation
6 MultiUndervolt
7 MultiOvercurr
8 MultiDesat
9 Heatsink OT
10 HeatsinkS OTUT
11 Intakeair OT
12 Motor OT
13 Drive overload
14 Motor overload
15 Bres overload
16 Phaseloss
17 Opt Bus fault
18 Opt 1 IO fault
19 Opt 2 IO fault
20 Opt Enc fault
21 External fault
22 Speed fbk loss
23 Overspeed
24 Speed ref loss
25 Emg stop alarm
26 Power down
27 ExtIO fault
28 FastLink fault
29 Brake fault
30Motor pre OT
31Mot phase loss
32Not Used2
33 Plc1 fault
34 Plc2 fault
