gefran ADV200 Functions Description And Parameters List

182 ADV200 • Troubleshooting
Code Errormessageshownon
thedisplay
Sub-code Description
XXXXH-X The XXXXH-X code indicates the reason for the error: take note for examination with the
service centre.
Solution:If the alarm was a consequence of a variation to the drive configuration (parameter setting, instal-
lation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
42 Traperror
Condition:this condition can occur during operation when the trap micro protection is enabled; the alarm is
included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code (SubHandler-Class) indicates the reason for the error: take note for
examination with the service centre.
Solution: If the alarm was a consequence of a variation to the drive configuration (parameter setting,
installation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
43 Systemerror
Condition: this condition can occur during operation when the operating system protection is enabled; the
alarm is included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X code (Error-Pid) indicates the reason for the error: take note for examination
with the service centre.
Solution:If the alarm was a consequence of a variation to the drive configuration (parameter setting,
installation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
44 Usererror
Condition:this condition can occur during operation when the software protection is enabled; the alarm is
included in the list of alarms and alarm log. After this alarm:
- the drive automatically runs a reset
- motor control is not available.
XXXXH-X The XXXXH-X (Error-Pid) code indicates the reason for the error: make a note of this to
discuss it with the service centre.
Solution:If the alarm was a consequence of a variation to the drive configuration (parameter setting, instal-
lation of an option, downloading of a PLC application), remove it.
Switch the drive off and then switch it on again.
45 Paramerror
Condition:if an error occurs during the enabling of the parameter database saved in the Flash memory; the
alarm is included in the list of alarms and alarm log.
XXXH-X The code XXXXH-X indicates the IPA of the parameter that has been set outside the range
allowed when the database is enabled.
Solution:Set the parameter causing the error to a value within the range and run Saveparameter. Switch
the drive off and then switch it back on again.
If the IPA of the parameter is not shown in the manual, contact the service centre.
46 Loaddefault
Condition:this can occur during loading of the parameter database saved in the Flash memory
it is normal if it appears in the following conditions: the first time the drive is switched on, when a new
version of the firmware is downloaded, when the regulation is installed on a new size, when a new region is
entered. If this message appears when the drive is already in use it means there has been a problem in the
parameter database saved in the Flash memory.
If this message is displayed the drive restores the default database, i.e. the one downloaded.
0001H-1 The database saved is not valid
0002H-2 The database saved is not compatible
0003H-3 The saved database refers to a different size and not to the current size
0004H-4 The saved database refers to a different region and not to the current region
Solution:Set the parameters to the desired value and run Save parameter
47 Plccfgerror
Condition: this can occur during loading of the MDPLC application
The Mdplc application present on the drive is not run.
0004H-4
The application that has been downloaded has a different Crc on the DataBlock and Func-
tion table.
0065H-101 The application that has been downloaded has an invalid identification code (Info).
0066H-102 The applciation that has been downloaded uses an incorrect task number (Info).
0067H-103 The application that has been downloaded has an incorrect software configuration.
