gefran ADV200 Functions Description And Parameters List

ADV200 • Functions description and parameters list 69
This parameter contains the value of the multiplier factor to apply to the analog reference of the expansion card
calculated using the Analoginpgaintunefunction.
Example:
An external analog reference only reaches a maximum of 9.8V instead of 10V. 1.020 (10V : 9.8V) is entered as
the Analoginpxgain parameter.
The same result can be achieved using the Analoginpxgaintune function. This parameter can be selected
from the keypad menu. The maximum analog value available (in this case 9.8V) must be present on the termi-
nal, with positive polarity. Press the Enter key on the keypad to start analog reference self-tuning.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.42 1626Aninp1Xsignsrc LINK 16 6000 0 16384 ERW FVS
14.53 1676Aninp2Xsignsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal to be assigned to the relative digital input of the expansion card for
selecting the direction of rotation of the motor. The functions that can be associated with the digital outputs are
listed in the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.43 1632Analoginp1Xdest ILINK 0 0 0 ER FVS
14.54 1682Analoginp2Xdest ILINK 0 0 0 ER FVS
The function for which the relative analog input of the expansion card has been programmed and on which it
acts is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.55 5410Analoginp0Extmon INT16 16 0 -32768 32767 ER FVS
14.56 5412Analoginp1Extmon INT16 16 0 -32768 32767 ER FVS
14.57 5414Analoginp2Extmon INT16 16 0 -32768 32767 ER FVS
14.58 5416Analoginp3Extmon INT16 16 0 -32768 32767 ER FVS
14.59 5418Analoginp4Extmon INT16 16 0 -32768 32767 ER FVS
14.60 5420Analoginp5Extmon INT16 16 0 -32768 32767 ER FVS
14.61 5422Analoginp6Extmon INT16 16 0 -32768 32767 ER FVS
14.62 5424Analoginp7Extmon INT16 16 0 -32768 32767 ER FVS
These parameters show the value of the analog input.
Analog input modules can have a resolution of 12 to 16 bits and scaling may vary from manufacturer to manu-
facturer.
E.g.:
12-bit module
Signalconnected
Moduleconfiguration
Variant1 Variant2 Variant3 Variant4
-10V..+10V -2048..+2047 -32768..+32767 -16384..+16383
0V..+10V 0..+4095 0..+2047 0..+32767 0..+65535
4..20mA 0..+32767 +6553..+32767 +3276..+16383
16-bit module
Signalconnected
Moduleconfiguration
Variant1 Variant2 Variant3
-10V..+10V -32768..+32767
0V..+10V 0..+65535 0..+32767
4..20mA
