ADV200 • Functions description and parameters list 137
1 Inp1=Inp2
2 Inp1!=Inp2
3 Inp1<Inp2
4 Inp1>Inp2
5 |Inp1|=|Inp2|
6 |Inp1|!=|Inp2|
7 |Inp1|<|Inp2|
8 |Inp1|>|Inp2|
If set to 0 the comparator is not enabled
If set to 1 the comparator output is enabled when the value of Compare digital inp 1 is inside the window
resulting from the value of Compare digital inp 2 ± the tolerance set via the Comparator Window.
If set to 2 the comparator output is enabled when the value of Compare digital inp 1 is not inside the window
resulting from the value of Compare digital inp 2 ± the tolerance set via the Comparator Window.
If set to 3 the comparator output is enabled when Compare input 1 is less than Compare input 2.
If set to 4 the comparator output is enabled when Compare input 1 is greater than Compare input 2.
If set to 5 the comparator output is enabled when the value of Compare digital inp 1 is inside the window
resulting from the absolute value of Compare digital inp 2 ± the tolerance set via the Comparator Window.
If set to 6 the comparator output is enabled when the absolute value of Compare digital inp 1 is not inside the
window resulting from the absolute value of Compare digital inp 2 ± the tolerance set via the Comparator
Window.
If set to 7 the comparator output is enabled when the absolute value of Compare digital inp 1 is less than the
absolute value of Compare digital inp 2.
If set to 8 the comparator output is enabled when the absolute value of Digital compar inp1 is more than the
absolute value of Digital compar in2.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.11.6 3672 Compare window perc FLOAT 0.0 0.0 100.0 ERW FVS
Setting of the tolerance window for comparing the Compare input 1 and Compare input 2 signals.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.11.7 3674 Compare delay s FLOAT 0.0 0.0 30.0 ERW FVS
Setting of the delay for signalling the result of the comparison.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.11.8 3676 Compare output BIT 16 0 0 1 ER FVS
The status of the comparator output is displayed:
0 The result of the set comparison is negative
1 The result of the set comparison is positive
