ADV200 • Parameters List 243

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

F - Parameters List (Expert)

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

1 - MONITOR

1.1 250 Output current A FLOAT 16/32 0.0 0.0 0.0 R FVS

1.2 252 Output voltage V FLOAT 16/32 0.0 0.0 0.0 R FVS

1.3 254 Output frequency Hz FLOAT 16/32 0.0 0.0 0.0 R FVS

1.4 256 Output power kW FLOAT 16/32 0.0 0.0 0.0 R FVS

1.5 288 Output cosphi FLOAT 0.0 0.0 0.0 ER FVS

1.6 3394 Output active curr A FLOAT 0.0 0.0 0.0 ER FVS

1.7 628 Ramp setpoint FF INT16 16/32 0 0 0 R FVS

1.8 664 Speed setpoint FF INT16 16/32 0 0 0 R FVS

1.9 260 Motor speed FF INT16 16/32 0 0 0 R FVS

1.10 270 DC link voltage V FLOAT 16/32 0.0 0.0 0.0 ER FVS

1.11 272 Heatsink temperature degC INT16 16 0 0 0 ER FVS

1.12 290 Motor temperature degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.13 292 Sensor inp X mon degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.14 1544 An inp 1 temp mon degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.15 1594 An inp 2 temp mon degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.16 1610 An inp 1X temp mon degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.17 1660 An inp 2X temp mon degC FLOAT 16 0.0 0.0 0.0 ER FVS

1.18 2342 Working load perc FLOAT 0.0 0.0 0.0 ER F_S

1.19 280 Torque current ref A FLOAT 16/32 0.0 0.0 0.0 ER FVS

1.20 282 Magnet current ref A FLOAT 16/32 0.0 0.0 0.0 ER F_S

1.21 284 Torque current A FLOAT 16/32 0.0 0.0 0.0 ER F_S

1.22 286 Magnet current A FLOAT 16/32 0.0 0.0 0.0 ER FVS

1.23 3212 Motor overload accum perc UINT16 16/32 0 0 100 ER FVS

1.24 368 Drive overload accum perc UINT16 16/32 0 0 100 ER FVS

1.25 3260 Bres overload accum perc UINT16 16/32 0 0 100 ER FVS

1.26 1066 Enable state mon BIT 16 0 0 1 R FVS

1.27 1068 Start state mon BIT 16 0 0 1 R FVS

1.28 1070 FastStop state mon BIT 16 0 0 1 R FVS

1.29 1100 Digital input mon UINT16 16 0 0 0 R FVS

1.30 1300 Digital output mon UINT16 0 0 0 R FVS

1.31 1200 Digital input X mon UINT16 16 0 0 0 R FVS

1.32 1400 Digital output X mon UINT16 0 0 0 R FVS

1.33 5400 Dig inp 0Ext mon UINT32 32 0 0 4294967295 ER FVS

1.34 5402 Dig inp 1Ext mon UINT32 32 0 0 4294967295 ER FVS

1.35 5450 Digital out 0Ext mon UINT32 32 0 0 0 ER FVS

1.36 5452 Digital out 1Ext mon UINT32 32 0 0 0 ER FVS

2 - DRIVE INFO

2.1 480 Control type ENUM Asy 0 0 R FVS

2 Synchronous

1 Asynchronous

2.2 482 Drive size UINT16 0 0 0 RS FVS

2.3 484 Drive family ENUM No power 0 0 RS FVS

0 No power

1 380V..480V

2 500V..575V

3 690V

4 230V
