244 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5 380V..480V LC
2.4 486 Drive region ENUM EU 0 1 R FVS
0 EU
1 USA
2.5 488 Drive cont current A FLOAT CALCF 0.0 0.0 RZS FVS
2.6 490 Firmware ver.rel UINT16 0 0 0 R FVS
2.7 496 Firmware type UINT16 0 0 0 R FVS
2.8 504 Application ver.rel UINT16 0 0 0 ER FVS
2.9 506 Application type UINT16 0 0 0 ER FVS
2.10 508 Application subver UINT16 0 0 0 ER FVS
2.11 510 Time drive power on h.min UINT32 0 0 0 ER FVS
2.12 512 Time drive enable h.min UINT32 0 0 0 ER FVS
2.13 514 Number power up UINT16 0 0 0 ER FVS
2.14 516 Time fan on h.min UINT32 0 0 0 ER FVS
2.15 526 Power file ver.rel UINT16 0 0 0 ER FVS
2.16 530 Slot1 card type ENUM None 0 0 R FVS
2.17 532 Slot2 card type ENUM None 0 0 R FVS
2.18 534 Slot3 card type ENUM None 0 0 R FVS
0 None
769 I/O 1
1793 I/O 2
2305 I/O 3
3329 I/O 4
1544 Enc 1
1800 Enc 2
520 Enc 3
776 Enc 4
1032 Enc 5
2056 Enc 7
4 Can/Dnet
260 Profibus
516 RTE
576 FastLink
320 I/O Ext
832 I/O FastLink
255 Unknown
2312 Enc 8
1288 Enc 6
5633 I/O 6
6401 I/O 7
7681 I/O 8
2.19 546 Fw enc sl2 ver.rel UINT16 0 0 0 R FVS
2.20 548 Fw enc sl2 type UINT16 0 0 0 R FVS
2.21 5300 Fw enc sl1-3 ver.rel UINT16 0 0 0 R FVS
2.22 5302 Fw enc sl1-3 type UINT16 0 0 0 R FVS
2.23 5724 Fw FastLink ver.rel UINT16 0 0 0 ER FVS
2.24 5726 Fw FastLink type UINT16 0 0 0 ER FVS
3 - STARTUP WIZARD
4 - DRIVE CONFIG
4.1 550 Save parameters BIT 0 0 1 RW FVS
4.2 552 Regulation mode ENUM V/f control 0 3 RWZ FVS
0 V/f control
