ADV200 • Functions description and parameters list 123
22.7 – FUNCTIONS/BRES OVERLOAD
Braking resistors may be subject to sudden overloads following failures.
Always protect resistors by using thermal protection devices.
These devices do not have to interrupt the circuit where the resistor is installed, but their auxiliary contact must
interrupt the power supply of the drive power section. If the resistor requires the presence of a protection con-
tact, this must be used together with the one belonging to the thermal protection device.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.1 3250 Bres control BIT 0 0 1 ERWZS FVS
Enabling of the overload control of the external braking resistor.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.2 3252 Bres value ohm FLOAT SIZE 5.0 1000.0 ERWS FVS
Setting of the ohm value of the external braking resistor.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.3 3254 Bres cont power kW FLOAT SIZE 0.1 100.0 ERWS FVS
Setting of the power that can be continuously dissipated by the external braking resistor.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.4 3256 Bres overload factor FLOAT SIZE 1.5 10.0 ERWS FVS
Setting of the external resistor overload factor.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.5 3258 Bres overload time s FLOAT SIZE 0.5 50.0 ERWS FVS
Setting of the intervention time of the external braking resistor overload.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.6 3272 Bres enable src LINK 16BIT 6002 0 16384 ERW FVS
Parameters IPA 3272 Bres enable src and IPA 3274 Bres enable inv manage enabling/disabling (by digital
input) of the internal BU connected to a braking resistance with or without protective klickson.
The internal BU must be enabled with parameter IPA 3250 Bres control.
It can be used two ways:
1) If you use a resistance with klickson, the protection contact can be linked to a digital input by appropri-
ately conguring IPA 3272 from selection list L_DIGSEL1. The digital input will enable the braking when
the temperature of the resistance is below the protection threshold or disable it when the temperature
exceeds the threshold.
2) If you use a resistance without klickson, you can use the state of an alarm such as (for example) [15]
Bres overload to enable the braking unit when the alarm is inactive:
- congure IPA 3272 Bres enable src = IPA 4708 Alm dig out mon 1 (from selection list L_DIGSEL1),
- set IPA 4700 Alarm dig sel 1 = [15] Bres overload,
- set IPA 3274 Bres enable inv = 1 to invert the logic state.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.7 3274 Bres enable inv BIT 0 0 1 ERW FVS
Inverts the logic state of the BU enable command from IPA 3272 Bres enable src.
0 Off: inversion disabled
1 On: inversion enabled
Warning
