gefran GFX4 User Manual

10
80395G_MHW_GFX4_09-2010_ENG
3 • ELECTRICAL CONNECTIONS
3.1 power connections
0,2 - 6mm
2
24-10AWG
Figure 12 model without fuse holder Figure 13 model with fuse holder
Table 4
Model
max current
30kW
16A
60kW
32A (30A)*
80kW
57A (40A)*
0,2 - 6mm
2
24-10AWG 0,5 - 16mm
2
20-6AWG
0,2 - 4mm
2
24-10AWG 0,2 - 4mm
2
24-10AWG 0,5 - 10mm
2
20-7AWG
0,25 - 4mm
2
23-10AWG 0,25 - 4mm
2
23-10AWG 0,5 - 10mm
2
20-7AWG
0,25 - 4mm
2
23-10AWG 0,25 - 4mm
2
23-10AWG 0,5 - 10mm
2
20-7AWG
0,5 - 0,6Nm 0,5 - 0,6Nm 1,2 - 1,5Nm
F1,F2,F3,F4 Line connection terminals
U1,U2,U3,U4 Load connection terminals
rigid
flexible
F1,F2,F3,F4 Line connection terminals
U1,U2,U3,U4 Load connection terminals
* UL certification
10 / 35
