Connection example for one 3-phase load, open triangle
Connection example for two 3-phase loads, star without neutral
Figure 40
Figure 41
P
Id =
___
3V
V = line voltage
Id = load current
P = total power
V
Id
V
Id
P
Id =
___
V
3
. V
V = line voltage
Id = load current
P = total power
27 / 35
