32
80395G_MHW_GFX4_09-2010_ENG
COMMUNICATION PORTS
PORT1 (present)
Function Local serial communication
Protocol ModBus RTU
Baudrate Settable to 1200,…,115200, (default 19,2Kbit/s)
Address node Settable by rotary switch
Type RS485
1500V isolation, double connector RJ10 telephone type 4-4
PORT2 (Fieldbus option)
Function Fieldbus serial communication
Protocol ModBus RTU, type RS485, baudrate 1200...115000Kbit/s
CANOpen 10K…1Mbit/s
DeviceNet 125K…0,5Mbit/s
Profibus DP 9,6K...12 Mbit/s
Ethernet Modbus TCP 10/100Mbit/s
POWER (Solid state power units, 4 units)
Rated voltage 480Vac
Work voltage range 24…530Vac
Non-repetitive voltage 1200Vp
Zero switching voltage <20V
Rated frequency 50/60Hz self-setting
Rated current AC51 30KW 60KW 80KW
4x16A 4x32A (4x30)* 4x40A (4x40)* (single channel 57A ∑I = 160A)
Non-repetitive overcurrent (t=20msec) 400A 600A 1150A
I
2
t for fusion (t=1…10msec) 645A
2
s 1010A
2
s 6600A
2
s
Critical Dv/dt with output deactivated 1000V/μsec
Rated isolation voltage 4000V
FUNCTIONS
Safety Detects short circuit or open probe circuit, probe ,
power supply failure, LBA alarm, HB alarm
Selection °C/°F Configurable
Linear scale range -1999…9999
Control actions 4 control loops:
Double action (heat/cool) Pid, on-off
Self-tuning at power-up, Continuous Autotuning, One-shot Autotuning
pb-dt-it 0,0...999,9 % – 0,00...99,99 min – 0,00...99,99 min
Action – control outputs heat/cool – ON/OFF, PWM, GTT
Heat/cool max. power limitation 0,0…100,0 %
Cycle time - Softstart 0…200 s - 0,0…500,0 min
softstart at phase slicing
Fault power setting -100,0…100,0 %
Shut-down function Maintains sampling of process variable PV; when active, disables
control
Configurable alarms Alarm is assigned to an output, configurable as:
maximum, minimum, symmetrical, absolute/deviation, LBA, HB
Alarm masking Exclusion at power-up, latch, reset by digital input
Diagnostics SCR in short circuit (presence of current with control OFF)
SCR open (presence of voltage on SCR with control ON)
Load interrupted or no voltage (no current, no voltage on SCR
with control ON)
Connection and load types 4 loads single-phase ,
Selection with dip-switches 2 loads 3-phase, star without neutral controlled on two phases
2 loads 3-phase, closed triangle controlled on two phases
1 load 3-phase, star with neutral controlled on one phase
1 load 3-phase, open triangle controlled on one phase
(with 3-phase load, 4 CTs are needed if diagnostics is required))
* UL certificate
32 / 35
