5.1 Voltage/Current Table
workingnominalrange
110
480
24...530
Voltage (Vac)
max
for channel
16
Current (Amp)
Model
GFX4
30
(4x16A)
max for
single channel
single
channel
total
contemporary
(1x16x110)
1,7
(16x110)
1,7
(4x16x110)
7
Power (kW)
230
(1x16x230)
3,6
(16x230)
3,6
(4x16x230)
14,7
400
(16x400
6,4
(16x400)
6,4
(4x16x400)
25,6
480
(1x16x480)
7,6
(16x480)
7,6
(4x16x480)
30,7
110
480
24...530
32 (30)*
60
(4x32A)
(4x30A)*
(32x110)
3,5
(32x110)
3,5
(4x32x110)
14
230
(1x32x230)
7,3
(32x230)
7,3
(4x32x230)
29,4
400
(1x32x400)
12,8
(32x400)
12,8
(4x32x400)
51,2
480
(1x32x480)
15,3
(32x480)
15,3
(4x32x480)
61,4
110
480
24...530
40*
80
(4x40A)
(1x57x110)
62,7
(40x110)
4,4
(4x40x110)
17,6
230
(1x57x230)
13,1
(40x230)
9,2
(4x40x230)
36,8
400
(1x57x400)
22,8
(40x400)
16
(4x40x400)
64
480
(1x57x480)
27,3
(40x480)
19,2
(4x40x480)
76,8
57
* UL Certificate
GENERAL DATA
Power supply 24Vdc ±25%, max 8VA
Indicators Eight LEDs:
RN CPU in run state
ER fault signal
DI1, DI2 state of digital inputs
O1,…,O4 state of outputs
Protection IP20
Work/storage temperature 0…50°C (see dissipation curves) / -20…70°C
Relative Humidity 20…85% Ur non-condensing
Ambient work conditions indoor use, altitude up to 2000m
Installation DIN RAIL EN50022 o pannello tramite viti
Installation instructions Installation category II, pollution level 2, double isolation
Maximum surrounding air temperature 50°C (for UL).
Open type equipment
Weight
models 30Kw, 60Kw, 80Kw 1200g.
models 30Kw, 60Kw con fusibili 1600g.
5.2 Dissipation curves
Current [A]
Ambient temperature [°C]
DERATING
45
40
35
30
25
20
15
10
5
0
0 10 20 30 40 50 60
GFX4-80
GFX4-60
GFX4-30
