gefran SIEIDrive AVy Series User Manual

Ch.8141
——— Parameters lists ———
Value Access via
Keyp. RS485/Terminal Opt2-A
minmaxFactory BUS//PDC
Opt2-M
Output voltage 20
Voltage U 21
Voltage V 22
DC linkvoltage 23
Analog input 1 24
Analog input 2 25
Analog input 3 26
Flux 27
Active
power 28
Torque 29
Rradapoutput 30
Pad 0 31
Pad 1 32
Pad 4 33
Pad 5 34
Flux reference 35
Pad 6 38
PID output 39
Feed fwd power 78
Out vlt level 79
Fluxlevel 80
F act spd(rpm) 81
FTcurr (%) 82
Spddrawout 84
PL next factor 87
P
L active limit 88
Scale output 162 Float -10.000 10.000 1.000
Ö
R/W - -
Select output 2 67 U16 0 88 T current (14)
Ö
R/Z - -
(Select like output 1)
Scale output 2 63 Float -10.000 10.000 1.000
Ö
R/W - -
Select output 3 68 U16 0 88 Current U (17)
Ö
R/Z - -
(Select like output 1)
Scale output 3 64 Float -10.000 10.000 1.000
Ö
R/W - -
Select output 469U16 0 88 Motor current (16)
Ö
R/Z - -
(Select like output 1)
Scale output 465 Float -10.000 10.000 1.000
Ö
R/W - -
Select input 170U16 0 28Ramp
ref1(4)
Ö
R/Z - -
OFF 0
Jogreference 1
Speed ref1 2
Speed ref 2 3
Ramp ref1 4
Ramp ref 2 5
T current ref1 6
T current ref 2 7
Adap reference 8
T current lim 9
T current lim + 10
T current lim - 11
Pad 0 12
Pad 1 13
Pad 2 14
Pad 3 15
Load comp 19
PID offset 0 21
PI
centralv3 22
PID feed-back 23
V/f fluxlevel 24
Fluxlevel 25
Out vlt level 26
Speed ratio 28
Parameter No Format
I/O CONFIG\Analog inputs \Analog input 1
I/O CONFIG\Analog outputs \Analog output 4
I/O CONFIG\Analog outputs \Analog output 3
I/O CONFIG\Analog outputs
\Analog output 2
