AVy - HGB
Ch.5 68
Table 5.3.1.3: Jumpers on Regulation Card RV33-3
Designation Function Factory setting
S5 - S6 Terminating resistor for the serial interface RS485 ON (*)
ON= Termination resistor IN
OFF= No termination resistor
S8
Adaptation to the input signal of analog input 1 (terminals 1 and 2)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10 V / -10...+10 V
S9
Adaptation to the input signal of analog input 2 (terminals 3 and 4)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10 V / -10...+10 V
S10
Adaptation to the input signal of analog input 3 (terminals 5 and 6)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10 V / -10...+10 V
S11 - S12 - S13 Encoder setting ( jumpers on kit EAM_1618 supplied with the drive) OFF
S14 - S15 - S16 ON=Sinusoidal SE
OFF=Digital DE
S17 Monitoring of the C-channel of the digital encoder OFF
ON=C-Channel monitored
OFF=C-Channel not monitored (required for single-ended channels)
S18 - S19 Encoder setting B
S20 - S21 Pos. B= reserved
Pos. A= reserved
S22 - S23 Analog input 3 enabling (alternative with SESC encoder) B
Pos. A= reserved
Pos. B=analog input 3 enabled
Pos. OFF= resolver
S26 - S27 Reserved ON
S28
Encoder Internal power supply selection
ON/ON=+5V
OFF/OFF=+8V
ON/ON
S29 Internal use A
S30
Second encoder qualifier input
A=from EXP-… board
B=from digital input "3" on RV33-4
A
Jumper to disconnect 0V (+24V power supply) from ground ON
ON = 0V connected to ground (hard-wire)
OFF = 0V disconnected from ground
Jumper to disconnect 0V (regulation board) from ground ON
ON = 0V connected to ground (hard-wire)
OFF = 0V disconnected from ground
S36 Internal use not mounted
S37 Internal use not mounted
S38-S39 Internal use ON
Power supply for the serial interface RS485 OFF
ON = Internal power supply (from pins XS.5 / XS.9)
OFF = External power supply (to pins XS.5 / XS.9)
Ay4060
(*)
on multidrop connection the jumper must be ON only for the last drop of a serial line
(**)
see chapter 5.4
S40-S41
(**)
S34
S35
Table 5.3.1.4: RV33 Regulation Card Switch S3 Settings
Type 1007 1015 1022 1030 2040 2055 2075 3110 3150 4185 4220 4300 4370 5450 5550 6750 7900 71100 71320 81600 82000
S3-1
ON OFF ON OFF OFF ON OFF ON OFF OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
S3-2
OFF ON ON OFF OFF OFF ON ON OFF ON OFF ON ON OFF OFF ON ON OFF OFF ON OFF
S3-3
OFF OFF OFF OFF ON OFF OFF OFF ON ON ON ON ON OFF OFF OFF OFF ON ON ON ON
S3-4
OFF OFF OFF OFF OFF OFF OFF OFF OFF ON OFF OFF OFF ON ON ON ON ON ON ON ON
S3-5
ON ON ON OFF ON OFF OFF OFF OFF ON OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF ON
S3-6
OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
S3-7
ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON ON
S3-8
OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
avy4080
The devices are factory set accordingly.When fitting a regulation card as a spare, remember to set dip-switch S3 and encoder
jumpers accordingly.
