1.5.2 Jumpers setting
Encoder / Jumpers setting S11 S12 S13 S14 S15 S16 S17 S18 S19 S20 S21 S22 S23
DE OFF OFF OFF OFF OFF OFF ON (*)
------
SE ON ON ON ON ON ON
- ------
ai3150
- DE: 5V digital incremental encoder with
A/A,B/B,C/C
- SE: 5V sinusoidal incremental encoder with
A/A,B/B,C/C
(*) If the encoder is not provided with the zero channel S17=OFF
1.5.3 Maximum cable length for encoder terminals
Cable section [mm
2
]
0.22 0.50.751 1.5
Max Length m [feet] 27 [88] 62 [203] 93 [305] 125 [410] 150 [492]
avy3130
