AVy - HGB
Ch.5 78
5.6.2. External fuses of the power section DC input side
Use the following fuses when a SR-32 Line Regen converter is used (see SR-32 instruction book for other
details).
Table 5.6.2.1: External fuses type for DC input side
Fuses type
Europe USA
1007 Z14GR6 A70P10 FWP10A14F
1015
1022
1030
2040
2055 Z14GR20 A70P20-1 FWP20A14F
2075 Z14GR32 A70P30-1 FWP30A14F
3110 Z14GR40 A70P40-4 FWP40B
3150 Z22GR63 A70P60-4 FWP60B
4185 S00C+/üf1//80/80A/660V A70P80 FWP80
4220
S00C+/üf1//80/80A/660V A70P80 FWP80
4300
S00C+/üf1//80/100A/660V A70P100 FWP100
4370
S00C+/üf1//80/125A/660V A70P150 FWP150
5450
S00C+/üf1/80/160A/660V A70P175 FWP175
5550
S00üF1/80/200A/660V A70P200 FWP200
6750
S1üF1/110/250A/660V A70P250 FWP250
7900
S1üF1/110/315A/660V A70P350 FWP350
71100
S2üF1/110/400A/660V A70P400 FWP400
71320
S1üF1/110/500A/660V A70P500 FWP500
81600
S1üF1/110/500A/660V A70P500 FWP500
82000
S1üF1/110/600A/660V A70P600 FWP600
avy4140
Z14GR16 A70P20-1 FWP20A14F
Drive type
Z14GR10 A70P10 FWP10A14F
Fuse manufacturers: Type Z14..., Z22, S00 ..., S1..., S2... Jean Müller, Eltville
A70P... Gould Shawmut
FWP... Bussmann
NOTE! The technical data of the fuses, e.g. dimensions, weights, heat dissipation, auxiliary
contactors, are reported in the corresponding data sheets.
5.6.3. Internal fuses
Table 5.6.3.1: Internal fuses
Drive type Designation Protection of Fuse (source) Fitted on:
Power card PV33-4-"D" and higher
Power card PV33-5-"B" and higher
1007 to 82000 F1 +24V Resettable fuse Regulation card RV33-1C and higher
6750 to 71320 F3
Fans
transformer
2.5A 6.3x32
(Bussmann: MDL 2.5, Gould
Shawmut: GDL1-1/2, Siba: 70 059
76.2,5 , Schurter: 0034.5233)
Bottom cover (power terminals side)
avy4145
2Afast5x20mm(Bussmann:
SF523220 or Schurter:
FSF0034.1519 or Littlefuse:
217002)
4185 to 82000 F1 +24V
