gefran SIEIDrive AVy Series User Manual

Ch.347
——— Inspection procedure, component identification and standard specification ———
Table 3.3.3.1: Nominal Drive Current
1007 1015 1022 1030 2040 2055 2075 3110 3150 4185 4220 4300 4370 5450 5550 6750 7900 71100 71320 81600 82000
Continuous service, no overload (IEC 146 class 1) [A] 2.4 4 5.6 7.5 9.6 12.6 17.7 24.8 33 39 47 63 79 93 114 142 185 210 250 324 400 Overload service 150%x60s followed by I
N
, min. cycle time 360s
(IEC 146 class2)
[A] 2.2 3.6 5.1 6.8 8.7 11.5 16.1 22.5 29.9 35 43 57 72 85 104 129 168 191 228 295 364
Overload service 200%x10s followed by I
N
, min. cycle time 30s
[A] 1.6 2.7 3.8 5.1 6.5 8.6 12.0 16.9 22.4 27 32 43 54 63 78 97 126 143 171 221 273
Overload service 200%x60s followed by I
N
, min. cycle time 160s
[A] 1.6 2.7 3.8 5.1 6.5 8.6 12.0 16.9 22.4 27 32 43 54 63 78 97 126 143 171 221 273
Overload service 250%x10s followed by I
N
, min. cycle time 25s
[A] 1.3 2.2 3.0 4.1 5.2 6.8 9.6 13.5 18 21 26 34 43 51 62 78 101 115 137 177 218
Overload service 300%x10s followed by I
N
, min. cycle time 25s
[A]1.11.82.53.44.35.78.011.215182129364252658496114147182
Overload service 300%x60s followed by I
N
, min.cycle time 130s
[A]1.11.82.53.44.35.78.011.215182129364252658496114147182
Continuous service, no overload (IEC 146 class 1) [A] 2.1 3.5 4.9 6.5 8.3 11 15.4 21.6 28.7 34 41 55 69 81 99 124 161 183 218 282 348 Overload service 150%x60s followed by I
N
, min. cycle time 360s
(IEC 146 class2)
[A] 1.9 3.2 4.4 5.9 7.6 10 14 19.6 26 31 37 50 63 74 90 112 146 166 198 257 317
Overload service 200%x10s followed by I
N
, min. cycle time 30s
[A] 1.4 2.4 3.3 4.4 5.6 7.5 10.5 14.7 19.5 23 28 37 47 55 68 84 110 125 148 192 238
Overload service 200%x60s followed by I
N
, min. cycle time 160s
[A] 1.4 2.4 3.3 4.4 5.6 7.5 10.5 14.7 19.5 23 28 37 47 55 68 84 110 125 148 192 238
Overload service 250%x10s followed by I
N
, min. cycle time 25s
[A] 1.1 1.9 2.7 3.5 4.5 6.0 8.4 11.7 15.6 19 22 30 38 44 54 67 88 100 119 154 190
Overload service 300%x10s followed by I
N
, min. cycle time 25s
[A]0.91.62.22.93.85.07.09.81315192531374556738399128158
Overload service 300%x60s followed by I
N
, min. cycle time 130s
[A]0.91.62.22.93.85.07.09.81315192531374556738399128158
avy2020
-I
2N
Rated output current (@ U
LN
=230-400Vac) :
-I
2N
xK
V
Rated output current (@ U
LN
=460/480Vac) :
