Ch.8143
——— Parameters lists ———
Value Access via
Keyp. RS485/Terminal Opt2-A
minmaxFactory BUS//PDC
Opt2-M
Drive ready 5
Overldavailable 6
Ramp+ 8
Ramp- 9
Speed limited 10
Undervoltage 11
Overvoltage 12
Heatsink sensor 13
Overcurrent 14
Overtemp m
otor 15
Externalfault 16
Failure supply 17
Pad A bit 18
PadBbit 19
Virt dig input 20
Speed fbkloss 25
Bus loss 26
Output stages 27
Hw opt 1failure 28
Opt 2 failure 29
Encoder 1 state 30
Encoder 2 state 31
Ovldmot state 32
Enab
le seq err 35
BU overload 36
Diameter calcst 38
Mot setup state 46
Input 1 cp match 49
Overload 200% 51
PL stop active 52
PL next active 53
PL time-out sig 54
Regulation ot 55
Module overtemp. 56
Heatsinkot 57
Intakeair o
t 62
Heatsink tmp thr 63
Digitaloutput 2 146 U16 0 63 Ramp-(9)
Ö
R/Z -
(Select like output 1)
Digitaloutput 3 147 U16 0 63Spd threshold(2)
Ö
R/Z -
(Select like output 1)
Digitaloutput 4 148 U16 0 63Overlda
vailable(6)
Ö
R/Z - -
(Select like output 1)
Digitaloutput 5 149 U16 0 63 Curr limit state (4)
Ö
R/Z - -
(Select like output 1)
Digitaloutput 6150 U16 0 63Over-voltage (12)
Ö
R/Z - -
(Select like output 1)
Digitaloutput 715
1 U16 0 63 Under-voltage (11)
Ö
R/Z - -
(Select like output 1)
Digitaloutput 8152 U16 0 63Over-current (14)
Ö
R/Z - -
(Select like output 1)
Relay 2 629 U16 0 63Speed zero thr (1)
Ö
R/Z 83-85 -
(Select like output 1)
Digi
talinput 1137 U16 0 67 OFF (0)
Ö
R/Z - -
OFF 0
Motor pot reset 1
Motor potup 2
Motor potdown 3
Motor potsign + 4
Motor potsign - 5
Jog + 6
Jog - 7
Failure reset 8
Parameter No Format
I/O CONFIG \ Digitalinputs
