Ch.8 148
Value Access via
Keyp. RS485/Terminal Opt2-A
minmaxFactory BUS//PDC
Opt2-M
Ovldmot state 658 U16 0 1Not ovrl (1) -R QD R
Overload 0 L
Not overload 1H
I_sqrt_t_accum [%]655 U16 0 100 0
Ö
R-R
Ovld Available 40
6 U16 0 1--RQD R
Overload not possible 0 L
Overload possible 1H
Overload 200% 1139 U16 0 1--RQD R
Overload not possible 0 L
Overload possible 1H
EnableBU 736 U16 0 1 Disabled (0)
Ö
R/W - -
Enabled 1
D
isabled 0
BU ovldtime [s]740 Float 0.1050.00 S
Ö
R/W
BU duty cycle [%] 741 U16 1 75S
Ö
R/W - -
BU DC vlt [V] 801 U16 0 2 1
Ö
R/W - -
230 0
400 1
460 2
PL stop enable 1083U16 0 2 0
Ö
R/W - -
Disabled 0
Enabled as Mst 1
Enabled as Slv 2
PL stop t limit [
%]1082 U16 0 F100
Ö
R/W - -
PL stop acc [rpm/s]1080U32 0 99999999 100
Ö
R/W - -
PL stop dec [rpm/s]1081 U32 0 10000 10000
Ö
R/W - -
PL stop vdc ref [V] 1084 U16 0 800 646
Ö
R/W - -
PL time-out [s]1087 U16 0 65535 10
Ö
R/W - -
PL stop P Gai
n [%]1086 Float 0.00 100.00 5.00
Ö
R/W - -
PL stopIGain [%]1085 Float 0.00 100.00 0.30
Ö
R/W - -
PL stop active 1088 U16 0 1Not active (0)
Ö
R-R
Not active 0
Active 1
PL active limit [%]1089 U16 - - -
Ö
R--
PL next active 1090U16
0 1Not active (0)
Ö
R-R
Not active 0
Active 1
PL next factor 1091 I16 032767 10000
Ö
R-R
PL time-out sig 1093U16 0 1Not active (0)
Ö
R-R
Not active 0
Active 1
PL time-out ack1094 U16 0 1Notacknowledged
Ö
R/W - R/W
Notacknowledged (0) 0
Acknowledged 1
P
L mains status 1092 U16 0 1Not ok (0)
Ö
R/W - R/W
Not ok 0
Ok 1
VDC Ctrl P Gain [%]1289 Float 0.00 100 10
Ö
R/W - -
VDC CtrlIGain [%]1290 Float 0.00 100 10
Ö
R/W - -
Gen access 58 U16 0 4Notconn. (0)
Ö
R/Z - -
Notconnected 0
F current ref 1
T current ref 2
Flux ref 3
Ramp ref 4
Gen frequency [Hz] 59 Float 0.1 62.5 1.0
Ö
R/W - -
Gen amplitude [%]60 Float 0.00 200.00 0.00
Ö
R/W - -
Gen offset [%] 61 Float -200.00 200.00 0.00
Ö
R/W - -
Parameter No Format
SPEC FUNCTIONS \Test generator
FUNCTIONS \Pwr loss stop f
FUNCTIONS \ Overload contr \ Ovlddrv contr
FUNCTION
S \Brakeunit
FUNCTIONS \ VDC controlf
