gefran SIEIDrive AVy Series User Manual

AVy -HGB
Ch.8 150
Value Access via
Keyp. RS485/Terminal Opt2-A
minmaxFactory BUS//PDC
Opt2-M
Input offset 559 Float
-2
31
2
31
-1
0
Ö
R/W - -
Output offset 560 Float
-2
31
2
31
-1
0
Ö
R/W - -
Input absolute 561 U16 0 1 OFF (0)
Ö
R/W - -
ON 1
OFF 0
Pad 0 503 I16 -32768 32767 0
Ö
R/W IA, QA R/W
Pad 1 504 I16 -32768 32767 0
Ö
R/W IA, QA R/W
Pad 2 505 I16 -32768 32767 0
Ö
R/W IA R/W
Pad 3 506 I16 -32768 32767 0
Ö
R/W IA R/W
Pad 4 507 I16 -32768 32767 0
Ö
R/W QA R/W
Pad 5 508 I16 -32768 32767 0
Ö
R/W QA R/W
Pad 6 50
9 I16 -32768 32767 0
Ö
R/W QA R/W
Pad 7 510 I16 -32768 32767 0
Ö
R/W - R/W
Pad 8 511 I16 -32768 32767 0
Ö
R/W - R/W
Pad 9 512 I16 -32768 32767 0
Ö
R/W - R/W
Pad 10513 I16 -32768 32767 0
Ö
R/W - R/W
Pad 11 514 I16 -32768 32767 0
Ö
R/W - R/W
Pad 12 515 I16 -32768 32767 0
Ö
R/W - R/W
Pad 13516 I16 -
32768 32767 0
Ö
R/W - R/W
Pad 14 517 I16 -32768 32767 0
Ö
R/W - R/W
Pad 15518 I16 -32768 32767 0
Ö
R/W - R/W
Bitword Pad A 519 U16 0 65535 0
Ö
R/W ID*, QD* R/W
Pad A Bit0 520U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 1 521 U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 2 522 U16 0 1
0 - R/W ID,QD R/W
Pad A Bit3 523U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 4 524 U16 0 1 0 - R/W ID,QD R/W
Pad A Bit5 525U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 6 526 U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 7 527 U16 0 1 0 - R/W ID,QD R/W
Pad A Bit 8
528 U16 0 1 0 - R/W QD*-
Pad A Bit 9 529 U16 0 1 0 - R/W QD*-
Pad A Bit 10 530 U16 0 1 0 - R/W QD*-
Pad A Bit 11 531 U16 0 1 0 - R/W QD*-
Pad A Bit 12 532 U16 0 1 0 - R/W QD*-
Pad A Bit 13 533 U16 0 1 0 - R/W QD*-
Pad A Bit 14 534 U16 0 1
0 - R/W QD*-
Pad A Bit 15 535 U16 0 1 0 - R/W QD*-
Bitword Pad B 536 U16 0 65535 0
Ö
R/W QD* R/W
PadBBit0 537 U16 0 1 0 - R/W QD R
PadBBit 1 538 U16 0 1 0 - R/W QD R
PadBBit 2 539 U16 0 1 0 - R/W QD R
PadBBit3 540U16 0 1 0 - R/W QD R
PadBBit 4 541 U16 0 1 0 - R/W QD R
PadBBi
t5 542 U16 0 1 0 - R/W QD R
PadBBit 6 543U16 0 1 0 - R/W QD R
PadBBit 7 544 U16 0 1 0 - R/W QD R
PadBBit 8 545U16 0 1 0 - R/W QD*-
PadBBit 9 546 U16 0 1 0 - R/W QD*-
PadBBit 10547 U16 0 1 0 - R/W QD*-
PadBBit 11 548 U16 0 1 0 - R/W QD*-
PadBBit 12 5
49 U16 0 1 0 - R/W QD*-
PadBBit 13 550 U16 0 1 0 - R/W QD*-
PadBBit 14 551 U16 0 1 0 - R/W QD*-
PadBBit 15552 U16 0 1 0 - R/W QD*-
SBI enable 1293
U16 0 1 0
Ö
R/W - -
Disabled
0
Enabled
1
Menu
Pdc in0 1095U16 0 65535 0
Ö
R/W - -
SPEC FUNCTIONS \Pad Parameters
Parameter
No Format
Accessible only with optionalField bus card
OPTIONS \ Option 1\ PDC config \ PDC inputs
OPTIONS \ Option 1
